Single Cylinder, 4-stroke, liquid cooled, 4-valve (Titanium intake and steel exhaust), cooling fan, electric start. (Back-up kick start available as an option.)
Bore:
88mm
Stroke:
63.4mm
Displacement:
385.6cc
Compression Ratio:
12.48:1
Valve Train:
Titanium Intake and Exhaust
Ignition:
Dual-Map Kokusan 200w output, On-Demand Traction Control
Spark Plug:
NGK LKAR8A-9
Lubrication:
Twin Oil Pumps with Cartridge Filter and Separate Compartments for Engine and Transmission.
Fuel System:
42mm Throttle Body with Dual Injectors>
Clutch:
Wet Diaphragm-style
Transmission:
6-speed
Final Drive:
O-ring chain
Chassis
Frame:
Molybdenum Steel/Double Cradle, with quick air filter access.
Wheelbase:
58.7”
Seat Height:
37”
Ground Clearance:
12.6”
Footrest Height:
16.3”
Dry Weight:
241 lbs. (wet weight, no fuel)
Electrical:
Trail Tech Voyager GPS unit
Fuel Tank Capacity:
2.4 US gallons
Front Suspension:
48 mm Sachs Open Cartridge with compression, rebound and spring prelaod adjustment.
Rear Suspension:
Aluminum Body Sachs Shock with adjustable rebound and hi/low speed compression
Front Wheel Travel:
11.6”
Rear Wheel Travel:
11.4”
Final Gearing:
15T front, 48T rear (Comes with 13T front for off road use)
